Technical Equipment

The Atlantic Theater is equipped with state-of-the-art audio, visual, and lighting technologies to enhance your event. For specific inquiries or customization requests, please contact our AV technician, Logan Dodson at logan.dodson@stucen.gatech.edu. When contacting the AV Technician, please include your reservation details, including the reservation number and date of the event.

Projector:

  • Panasonic PT-MZ16KU 3LCD SOLID SHINE Laser Projector
    • 16,000 Lumens
    • 1900x1200 Resolution

Screen:

  • Draper Access V 226"
    • Ratio: 21:10

Sources:

  • Wireless Video (Solstice)
  • Blu-Ray Player
  • Cinelink box (film streaming service)
    • Rights obtained by the client via SWANK can be downloaded on the Cinelink box and streamed in the theater.
  • HDMI for laptop connection
  • Built-in Desktop (Must be utilized for livestreaming and requires GT login)
    • HP Z2 Mini G3

Microphones:

  • 8 Shure SM58 Wireless Handheld Microphones
  • 8 Shure ULXD1 Wireless Bodypack Transmitters
  • 2 Shure CVG18-B Condenser Gooseneck Microphones
    • 1 located on the main lectern/podium
    • 1 located on the mobile lectern/podium

Cameras:

  • 3 Pan Tilt Zoom (PTZ) Cameras
    • (2) Front of the theater
    • (1) Back of the theater

Speakers:

  • Full Surround Sound
    • (3) Bose speakers mounted front stage
    • (2) Bose subwoofers mounted front stage
    • (8) Bose surround speakers mounted on rear and side walls

Lighting:

  • Full stage lighting with five presets:
    • Lectern Left: Front row lighting for the lectern on the left of the stage
    • Film: Low blue lighting for the full stage
    • Full Stage: All stage lighting on
    • Town Hall Meeting: Center stage brighten with edges dim (Screen cannot be used)
    • Cool White Stage: Front stage lighting set to a cooler light temperature
  • Lighting Controls: Ion Xe Control Board
    • Ability to create lighting shows with software or within the control booth

XLR Input:

  • 2 Wall-mounted XLR inputs available (Located on the left and right on stage)

XLR Output:

  • 6 Wall-mounted XLR outputs available (Located on the front of stage)

Additional Equipment:

  • 4 Floor Audio Wedges available for optimal sound distribution

Control Booth:

  • Mixer: Allen & Heath SQ-7 48 channel digital mixer
    • 32 onboard preamps
    • 16 line outputs
    • 33 faders / 6 layers
    • 16 assignable softkeys
    • 8 assignable soft rotaries

Seating Diagram and Ticketing

Seating

  • The Atlantic Theater can host 297 attendees in the audience
    • Lower section contains five rows: 84 seats plus 5 handicap accessible locations
    • Upper section contains nine rows: 208 seats
seats

Ticketing

Campus Tickets is the preferred ticketing provider for ticketed events in the Atlantic Theater. For more information and to fill out the client intake form, please visit the Campus Tickets website. Campus Tickets can provide general ticketing options, as well as assigned seating options for the Atlantic Theater.
